MOD Deckplate

MATERIAL	BS970 150 M19 or equal
FINISH	Self colour, normalised condition, hardness HB159-229
STANDARD	To admiralty pattern, drawing 002521434
CERTIFICATION	As standard; EC Declaration of Conformity
NOTE	This product is identified with a proof load, however , this is subject to the correct welding procedure being carried out

MOD Deckplates

1 file(s) 404.56 KB

Download

Category: Deckplates & Links

Description

Description

Proof	AP	Diameter	Diameter	Diameter	Width	Length	Thickness	Height	Product	Weight
Load	no			Eye Inside	Base	Base	Base	Overall	Code	Each
		a	a	b	c	d	e	f
T		inch	mm	mm	mm	mm	mm	mm		kg
2.00	4014	3/8	10	20	25	45	6	38	79001V	0.14
3.50	4015	1/2	12	25	35	60	8	50	79002V	0.33
5.50	4016	5/8	16	32	45	70	10	64	79003V	0.53
7.50	4017	3/4	19	38	50	85	12	76	79004V	0.77
9.60	4018	7/8	22	42	60	102	13	89	79005V	1.27
13.00	4019	1	25	50	70	115	16	100	79006V	2.00
15.75*	4020	1.1/8	28	57	76	130	18	114	79007V	2.90
20.00	4021	1.1/4	32	64	85	145	19	128	79008V	3.86
29.00	4023	1.1/2	38	76	100	170	22	152	79009V	6.58

size marked * is additional and proportional to the specification
*50mm Deckplate is C45 material

×
