Drop Forged Ring

MATERIAL	High tensile steel
SAFETY FACTOR	MBL equals 5 x WLL
STANDARD	BS 2902 – 1957
FINISH	Self colour
CERTIFICATION	As standard; EC Declaration of Conformity

Drop Forged Ring

1 file(s) 364.92 KB

Download

Category: Deckplates & Links

Description

Working	Diameter	Diameter	Width	Width	Product	Weight
Load Limit			Inside	Inside	Code	Each
	a	a	b	b
cwt	inch	mm	inch	mm		kg
11	1/2	13	2	50	79501	0.20
20	5/8	16	3	75	79506	0.42
25	3/4	19	3	76	79503	0.72
34	7/8	22	3.1/2	89	79504	1.14
44	1	25	4	100	79505	1.75
